The LONN-UL25 ultrasonic level meter provides continuous, non-contact liquid level measurement for water, oil, and chemical storage tanks. Using high-frequency pulse acoustic technology, it measures levels from 0 to 25 meters with ±0.25% accuracy. The integrated design combines transmitter, display, and RS485 communication in an IP65/IP68-rated housing, delivering 4–20mA analog output plus Modbus RTU digital interface. Ideal for industrial water treatment, petroleum storage, and chemical processing applications.

• Measurement Range: 0–5m / 0–10m / 0–15m / 0–20m / 0–25m (customizable)
• Blind Zone: 0.25m – 0.6m (range-dependent)
• Accuracy: ±0.25% – 0.5% FS
• Resolution: 1mm
• Output Signal: 4–20mA + RS485 Modbus RTU
• Power Supply: DC12V / DC24V / AC220V (with built-in lightning protection)
• Protection Rating: IP65 / IP68
• Operating Temperature: -20°C to +60°C
• Process Pressure: < 4 atmospheres
• Display: Integrated LCD (level or distance)
