Density Measurement
High-precision digital density meters for real-time monitoring and process control in industrial environments.
LONN-ND50 Integrated Online Viscosity Meter | LONNMETER
The LONN-ND50 is an inline industrial viscometer that measures liquid viscosity using a metal tuning fork vibration principle. Designed for inline installation in chemical, pharmaceutical, food, and petroleum refining processes, it delivers real-time 4–20mA and RS485 Modbus RTU outputs with Ex d II BT6 explosion-proof certification. Field-configurable via built-in meter menu.
- Viscosity Range: 0–10,000 mPa·s (calibratable to custom range)
- Viscosity Accuracy: ±2.5%
- Temperature Range (Media): 0–60°C
- Temperature Range (Ambient): -40–85°C
- Output Signal: 4–20mA active + RS485 Modbus RTU
- Signal Mode: 4-wire system
- Explosion Protection: Ex d II BT6
- Working Pressure : <1 MPa
- Power Supply: 24VDC
Inline Viscometer — LONN ND80 Vibrating Fork Viscometer-high-temp
LONN ND80 inline viscometer with vibrating fork technology for continuous viscosity measurement. ±1% FS accuracy, dual 4-20mA + RS485, Ex certified, ANSI flange, 316L/Hastelloy.
- Measurement Principle： Vibrating fork (tuning fork)
- Viscosity Range： 0 – 5,000 cP (segment calibratable)
- Viscosity Accuracy： ±1% FS
- Temperature Range： -10°C to +200°C (standard) / up to +400°C (high-temp)
- Output： Dual 4-20mA (viscosity + temperature) + RS485 Modbus
- Power Supply： 24V DC
- Process Connection： ANSI 150LB RF Flange
- Wetted Materials： 316L SS / Hastelloy C
Online Viscometer — LONN-DN60 Integrated Viscosity Meter
LONN-DN60 online viscometer with integrated sensor and transmitter. 0-5,000,000 cP range, Ex d IIC T6, 4-20mA + RS485. Wide temperature 0-300C. Built-in display.
- Measurement Principle： Tuning fork vibration
- Viscosity Range： 0 – 5,000,000 cP (segment calibratable)
- Viscosity Accuracy： ±3.0% of reading
- Explosion Protection： Ex d IIC T6 (flameproof)
- Output： 4-20mA + RS485 Modbus RTU
- Power Supply： 24V DC
- Medium Temperature： 0°C to +300°C
- Protection Class： IP67 / IP68 (probe)
Split Type Viscometer — LONN-DN100 Online Viscometer
LONN-DN100 split type viscometer for online viscosity measurement in hazardous areas. Ex d IIC T6 flameproof, 4-20mA + RS485 Modbus. Also measures density.
- Measurement Principle： Tuning fork vibration
- Viscosity Range： 0 – 10,000 mPa·s (calibratable segment)
- Viscosity Accuracy： ±2.5% of reading
- Explosion Protection： Ex d IIC T6 (flameproof)
- Output： 4-20mA active + RS485 Modbus RTU
- Power Supply： 24V DC
